XAH 600-2,000 CFM Horizontal Indoor Coil

Fully cased, "A" coil design horizontal unit with MaxAlloy™ coil technology

Coil MaxAlloy™ coil
Configuration Fully-cased, with field-installed or factory-installed bolt-on TXV available
Back to Top
Icon of a piggy bank on a grey background Rebates and Savings >
Dollar icon enclosed in two arrows forming a circle Financing >
Icon of a spanner head with a tickmark enclosed in an arrow Product Registration >
Icon of a cube enclosed in two arrows Warranty Lookup >

XAH 600-2,000 CFM Horizontal Indoor Coil

  • Overview
  • Features & Benefits
  • Specifications
  • Literature
    Find a Dealer

    QUALITY STARTS ON THE INSIDE

    Champion® Cased, Horizontal (XAH) Aluminum Indoor Coils are ideal for unique or tight-space configurations. These units feature a new, “A” coil design and are fully cased and designed to deliver optimized efficiency when matched with Champion® outdoor air conditioners or heat pumps. MaxAlloy™ aluminum indoor coils are specially engineered to handle demanding air conditioner and heat pump duty. Combined with staggered tube rows that ensure proper moisture removal, this smart design provides reliable, efficient performance. Designed for compliance with upcoming Department of Energy (DOE) 2023 regulations, XAH indoor evaporator coils will help your system meet more stringent minimum efficiency standards.
    QUALITY STARTS ON THE INSIDE

    Features

    • Long-life MaxAlloy™ aluminum coil provides lasting reliability
    • Horizontal design is ideal for tight spaces or other unique configuration needs
    • Delivers optimized efficiency when partnered with a matching Champion® furnace
    • Provides proper moisture removal with staggered tube rows
    • Handles demanding AC or heat pump duty
    • TXV kits available, featuring nonbraze, bolt-on connectors for quick and easy installation

    Benefits

    Lower Cost Of Ownership
    LOWER COST OF OWNERSHIP

    Through smart “A” Coil design and advanced MaxAlloy™ materials, the XAH indoor coil can reduce total cost of ownership through long-lasting reliability.

    Reliable Support
    RELIABLE SUPPORT

    Our Certified Comfort Expert™ contractors make sure your XAH indoor coil is installed and serviced correctly from day one.

    Confidence Guaranteed
    CONFIDENCE GUARANTEED

    A 10-year Parts Limited Warranty ensures years of dependability with industry-leading quality.

    DOE 2023 CERTIFIED

    The Department of Energy’s newest efficiency standards take effect in January 2023. XAH indoor evaporator coils are designed to meet these standards, are DOE 2023 certified and will help your system meet these stringent requirements. Learn more about DOE 2023 standards on our DOE 2023 page.
    Learn About DOE 2023

    WARRANTY

    With a Champion® residential system, comfort is more than a feeling – it’s a promise. Because Champion® home comfort systems are built to the highest standards and backed by the best warranties.
    Register Your Warranty

    Technical Specification

    Tonnage Range 1.5-5 tons Capacity 600-2,000 CFM
    Position Horizontal design Parts Warranty Code 10-year Parts Limited Warranty*
